Name： HX-220 Computer wire cutting machine

Published:2015-05-28 10:06:26Click to rate：

I. Features:

Recently electronic products, tend to light, thin, short, small claims, the more it tends to thin wires needed, short-term and high-precision, the machine just to play its biggest strengths. Previously considered difficult to process within a short 50mm, now there is no problem, even when the total length of only 1mm, while each of the two ends have to peeling 0.3mm, at the same time can be set to send line feed, back knife and then peeling and peeling back the speed, the line of separation can also be forced peeling to 99mm, the line of separation can not be ruled out before stripping and the injury to the whole difficulty of the center line.

Second, the specification:

Model	HX-220
Dimensions	450450360MM
Weight	39KG
Power supply	AC 110V/220V 50/60HZ
Power consumption	MIN.20W-MAX220W
Cutting length	0.1-60000MM
Stripping length	0.1-999MM (line of sight material may be)

Off error	Correctable
Applicable Wire	AWG # 10-AWG # 36 (line of sight material may be)
